Label Counting Machine

The  Label Counting Machine help you to count the number of labels on a roll and rewinding synchronously, reverse the direction of the labels as well. And the counting function including count meter and count piece or count number.
  • Brand:

    Lingtie
  • Item NO.:

    LTD-450A
  • Price Range:800 - 3000/$1
  • Shipping Port:

    Xiamen ,China
Product Detail

Product Name: Label Counting Machine

Label Counting Machine export 100 sets to all parts of the word every year which most of our OEM label counter machine, adopt mechanical shafts or air shafts, change various core sizes, roll diameter and speed adjustment, these units present the most versatile way to get the job done.

Application:

The equipment can Be Rewinding & Counting is done automatically by the machine at one time. The thickness of the main baking products ranges from 0.02-15 mm in flat packaging materials. And the counting function including count meter and count piece or count number.

The Features for the Label Counter Machine

  • Maximum  roll diameter: 450mm
  • Standard core size: 3 inches
  • Power Supply: 220v/0.12kw
  • Allowable Weight: 30kg
  • Magnetic Tension: 6N
  • the Machine Gross weight: 40KG
  • Dimensions: 660 x 400 x 580 mm ( L * W * H)

Customized Details for Label Counting Machine

  • 17.7” diameter roll capacity, 3” to 3” core. (standard air shaft )
  • Core Diameter – 1” to 6" Unwind and 1" to 6” Rewind (air shaft or mechanical shaft )
  • Label Width – Up to 15.7” (400-mm)
  • Roll Diameter – Up to 26.3” (670-mm)
  • Bi-directional rewind capability  ( Right to Left and Left to Right )
  • Count Meter, Count Piece, Tension Control, Web guide, dust removing, Static Eliminating for an option.



Relate Machine: Label slitter and rewinder machine


FAQ

1, Are you a manufacturer or a distributor?

  • We are a professional manufacturer for 15-years in China.
  • There are so many models of the Label Rewinder Machine in our workshop which ensure short delivery time and can reduce your waiting cost.

2, What kind of material does your Label Counting Machine rewind?

  • Most of the material could be rewind in roll form, including the elastic material. Before your order, you can send me some samples is the best way.
3, What the maximum width of the material could be rewind?
  • The standard width is 150mm, 170mm, 300mm & 600mm, and another width we can customize for the client.
4, Is there any additional function of your machine?
  • Yes, Count Meter, Count Piece, Tension Control, Web guide, dust removing, Static Eliminating for an option.
5, How many sizes of shafts do your machine use?
  • The standard shaft size is 25mm, 38mm, 76mm ( 3 inches), and another size we can customize for the client.
  • There are two kinds of shafts for choose, air shaft, and mechanical shaft. ( air shaft need a compressor to expand)

6, What is the maximum reel diameter of your machine?
  • The standard reel diameter is 300mm, 350mm, 450mm, 550mm, 600mm, 650mm, 670mm.
7, What's the Label Counting Machine price?
  • The price according to your side demands, and the price range: 800--7000 $
8, What are the Certifications of your machines?
  • We have CE Certificate & ISO Certificate


9, How can you promise that Each Component, 10-years non-rusting?

  • We have the Self-Machining CNC Center and each process under the strict quality control,  which is one of the conditions that ensure the stability of the Laber Counter Machine

10, We supply OEM/ODM Service to the worldwide clients.

11, What's the packing method of your label counter machine?
