Intermittent Rotary Letterpress Printing Machine
Brand:
LingtieItem NO.:
LTAC-280Payment:
T/T, T/CMarket Price:
$99999Shipping Port:
Xiamen ,China
Description of the Intermittent Rotary Letterpress Printing Machine
- Full-servo printing control system to ensure high running accuracy.
- A set of stencils can be printed in many sizes to save printing costs.
- The ink release system can control each color seat separately through the touchscreen, and it can choose automatic ink discharge and manual ink discharge.
- Automatic version function can entirely save materials and machine time, no need to manually fix the color seat; the system will automatically enter the locked state after adjustment.
- Automatic ink release: The system automatically adjusts the tension and ink under different printing speeds to ensure accurate alignment and the same print quality.
- Second printing device to meet customer's repeated printing process.
The parameter of the Intermittent Rotary Letterpress Label Printing Press
- Max. web width ：350 mm
- Max. Printing Area ： Intermittent Rotary: 50~305(L) x 270(w)
- Max. printing Area: Full Rotary: 340(w ）x 376 (L )
- Max. Speed ： 30-200 RPM , 12000 imp / hr
- Power supply ：3 phase, 80 A, 15 kW
- Machine weight ： 3500 KG (N.W.), 4500 KG (G.W.)
- Mechanical installation dimensions ：L 550 x W 120 x H 140 （CM）
Where to buy an Intermittent Rotary Letterpress Label Printing Press Machine ，tell me your needs the rest we can work out.
Lingtie (Xiamen) Machinery Co. Ltd. is a company specializes on R &D, Manufacture, CNC Machining, sales and services of Letterpress Label Printing Machine, automatic roll to roll silk screen printing machine, rewinding machine, label rewinding machine, roll-to-sheet cutting machine and ancillary equipment for 15 years. The total sales amount of the apparatus can reach 20 million every year. Lingtie Machinery service all over the world clients for 15 years also.
What is the Price of the Shaftless Intermittent Rotary Letterpress Label Printing Machine?
1. Tell us how many colors do you want to print?
2. Tell us what kind of the UV INK you used, the oil-based UV ink or water-based UV ink?
3. How many functions do you want to add?
-
Letterpress Label Printing Press
Intermittent Rotary Letterpress label Printing Press carry the patented technology - Automatic Registration Function widely use in sticker printing, film printing.
-
Letterpress Rotary Printing Machine
You can choose the Full Rotary Intermittent Label Printing or Semi-rotary Intermittent Printing according to your material dimension. It's printing speed reach 200 RPM （ 73 meters / min）.
-
Rewinder with thermal transfer printing
Rewinding with TTO thermal transfer overprint function, It can print date, code, serial number, etc. on label or material in roll form
-
Auctomatic Roll To Roll Heat Press Machine
Overview Quick Details Place of Origin: Fujian, China Applicable Industries: Garment Shops, Building Material Shops, Manufacturing Plant..... After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service Local Service Location: None Showroom Location: None Brand Name: Lingtie Condition: New Warranty: 1 year After-sales Service Provided: Free spare parts, Field installation, commissioning and training... Usage: Logo label heat transfer printing speed: 0-3600 Machine size: L680*W400*H745mm Weight: 80kg working table size: L1230*W400*H1500mm Printing size: 100*100mm Packaging & Delivery Selling Units: Single item Single package size: 150X50X150 cm Single gross weight:130.0 kg Package Type:wooden boxes for sea transportation Lead Time : 15 days after advanced payment. Video Description Apparel manufacturers, looking for alternatives to sew in t-shirt labels and garment tags have transitioned to tagless care labeling, which way can make the consumer more comfortable in their clothes and reduce costs. Speed, durability, and ease of use separate the Ling-tie Roll to Roll from all other roll label transfer presses. It is designed specifically for high production applications of tagless care labels. Short web paths, tool-less web guides, and quick release lower platens decrease change-over times and eliminate excessive waste. and its sensor adjustment is simple and capable of reading either side of the roll transfer. Max.printing area mm 100*100 Roll diameter OD mm 195 Roll diamter ID mm 25-76 Temperature celsius room temperature -200 Power v 1p 220 Air source mpa 0.4-0.6 Speed t/h 0-3600 Weight kg 80 Size mm L680*W400*H745 The Roll to Roll Label Press is designed for many customers' requested. The customer needs the Fully automatic roll to roll label press to reduce their cost, improve the output effectively. and they know Lingtie Machinery plant has the factory price to offer. For this machine specification: *Maximum and minumum width of transfer label? ————the range is 0-150mm *What is max diameter of label rolls? ————195mm *Max.temperature how many degree? ————200°C *Can we arrangment pressing time? ————Yes *Pressure system oil or air? ————Air *What is dimension of printing area? ————100x100mm,200x200mm,300x300mm,the size also can be custom made
